Suggested number of coating layers:
Second layer, dry film thickness of 70 μ m
Front supporting paint:
Matched with 706 anti rust paint, F53-31 (712) red lead phenolic anti rust paint, C53-31 (716) red lead alkyd anti rust paint, C53-38 aluminum iron alkyd anti rust paint, F53-34 zinc yellow phenolic anti rust paint, C53-41 iron red multi-purpose primer, F06-11 (336-1) white phenolic anti rust paint and other phenolic and acid type anti rust paints; It can also be matched with 842 epoxy cloud iron anti rust paint.
Construction conditions:
The substrate temperature must be 3 ℃ above the dew point
Suitable for use as a topcoat on ship hulls and superstructures above the waterline, as well as on onshore steel structures
Color and appearance
|
Product model
|
Color and appearance
|
|
C43-31(861-2)
|
Light gray, shiny
|
|
C43-31(863)
|
Light gray, shiny
|
|
C43-31(864)
|
Milk yellow, shiny
|
|
C43-31(865-1)
|
Medium gray, shiny
|
|
C43-31(867)
|
White, shiny
|
|
C43-31(869-1)
|
Blue gray, shiny
|
|
C43-31(870-1)
|
Light gray, shiny
|
|
C43-31(882-1)
|
Black, shiny
|
Construction parameters, volume and solid content
|
PRODUCT MODEL
|
Density about
g/cm3
|
Volume Solid
share*%
|
Dry film thickness
μm
|
Wet Film Thickness
μm
|
Theoretical coating amount
m2/kg
|
|
861-2
|
1.12
|
45±3
|
35
|
78
|
11.5
|
|
863
|
1.13
|
48±3
|
35
|
73
|
12.2
|
|
864
|
1.3
|
45±3
|
35
|
78
|
11.5
|
|
865-1
|
1.24
|
48±3
|
35
|
73
|
11.6
|
|
867
|
1.12
|
46±3
|
35
|
76
|
11.8
|
|
869-1
|
1.19
|
45±3
|
35
|
78
|
10.3
|
|
870-1
|
1.34
|
45±3
|
35
|
78
|
10.6
|
|
882-1
|
0.96
|
44±3
|
35
|
79
|
12.5
|
